| Magnification: | 15-35x |
| Objective Lens Diameter: | 70mm (2.75") |
| Focal Length of Objective Lens: | 279.62mm (11") |
| Angular Field of View: | 2.2° |
| Linear Field of View (@1000 yds) / @1000 m): | 111 ft (38.4 m) @15x |
| Exit Pupil: | 4.7 @15x / 2.0 @35x |
| Eye Relief: | 20.3mm @15x |
| Close Focus: | 73.8 ft (22.5 m) |
| Interpupillary Distance (max): | 72mm (2.83") |
| Interpupillary Distance (min): | 56mm (2.20") |
| Diopter Adjustment Range: | -4 to +10 |
| Twilight Factor: | 37.41 |
| Relative Brightness: | 12.25 |
| Limiting Stellar Magnitude: | Ideal: 11.73
Moderate: 10.73
Poor: 9.73 |
| Lens Coatings: | Multi-Coated |
| Prism Glass (Type): | BaK-4 |
| Prism Coatings: | N/A |
| Weight: | 53oz (1503 g) |
| Environmental Protection: | Water Resistant |
| Nitrogen Filled: | No |
| Tripod Adaptable: | Yes |
| Carrying Case: | Nylon |
| Dimensions: | 228mm x 120mm x 300mm (9.0" x 4.7" x 11.8") |
| Included Items: | Objective lens caps
Tripod adapter
Rainguard
Carrying case
Neck strap
Lens cloth
Instruction manual |
| Solar Warning | - Never look directly at the Sun with the naked eye or with this optic. Permanent and irreversible eye damage may result.
- Never use your optic to project an image of the Sun onto any surface. Internal heat build-up can damage the optic and any accessories attached to it.
- Never leave your optic unsupervised. Make sure an adult who is familiar with the correct operating procedures is with your optic at all times, especially when children are present.
|
